Industrial High Temperature Insulation 99% Alumina Ceramic Ring

Name: Industrial High Temperature Insulation 99 Alumina Ceramic Ring
Brand: China
Price: 1 USD

China Industrial High Temperature Insulation 99% Alumina Ceramic Ring wholesale

Brand Name : China

Model Number : 008

Place of Origin : Suzhou,China

MOQ : 100pcs

Price : Negotiable

Payment Terms : T/T

Supply Ability : 10000 Piece/Pieces per Month

Delivery Time : 25 days

Packaging Details : Box, Carton, Wooden, Bag etc. Customized package

Product name : Industrial High Temperature Insulation 99% Alumina Ceramic Ring

Material : Alumina Ceramic

Application : Industrial Ceramic

Length : 3mm ~ 2000mm

Water Absorption : 0%

Electrical Insulation : excellent

Density : 3.9g/cm3

Contact Now

Industrial High Temperature Insulation 99% Alumina Ceramic Ring

Description:

Alumina Ceramic is the most cost effective and widely used material in the family of engineering ceramics. The raw materials from which this high performance technical grade ceramic is made are readily available and reasonably priced, resulting in good value for the cost in fabricated alumina shapes. Alumina Ceramic may be used in applications that require high elevated temperatures, High dielectric strength, excellent electrical resistance, wear or corrosion resistance, high temperature capability. High Electrical insulation.

Technical Parameters:

Test item/Unit	Numerical Value			Test item/Unit	Numerical
Product Material	Alumina		Zirconia	Product Material	Alumina		Zirconia
Component Content %	≥99%	≥95%	≥90%	Volume Resistance MM	>1012	>1012	>1012

Sintering Temp ℃	1780-1800	1650-1680	1550-2600	Bending Strength Mpa	400	320	1100

Specific Gravity g/cm3	≥3.8	≥3.6	>6	Thermal Expansion Coefficient'10'	6.8-8.0	6.2-8.5	6.9-10

Breakdown Voltage Strength kv/mm	15	15	15	Roughness um	≤0.8	≤0.8	≤0.8

Bibulous Rate%	<0.01	<0.01	<0.01	Mirror Polished Ra	≤0.05	≤0.1	≤0.05
Anti Pressure Mpa	3700Mpa	2400Mpa	5000Mpa	Thermal Conductivity W/m.k	25	20	25

Hardness Hra	≥88	≥82	≥88	Temperature Resistance ℃	1700	1600	1800

Advantages:

1. Resistant to elevated temperatures.
2. High hardness.
3. Good wear resistance.

Application:

It is widely used in electronic, electrical, mechanical, chemical, metallurgical, textile, and other industries,etc.
